arcgisutils is designed as the backbone of the {arcgis}
meta-package.
arcgisutils is a developer oriented package that provides the basic functions to build R packages that work with ArcGIS Location Services. It provides functionality for authorization, Esri JSON construction and parsing, as well as other utilities pertaining to geometry and Esri type conversions.
Install arcgisutils from CRAN.
Or, you can install the development version of arcgisutils r-universe with:
Authorization tokens are provided through the functions auth_code()
, auth_client()
, auth_user()
, and auth_binding()
. Additional token validation functions are provided via refresh_token()
and validate_or_refresh_token()
.
Tokens are managed in a session based cache using set_arc_token()
and unset_arc_token()
. They are fetched using arc_token()
. Here is a minimal example:
library(arcgisutils)
#>
#> Attaching package: 'arcgisutils'
#> The following object is masked from 'package:base':
#>
#> %||%
tkn <- auth_client()
set_arc_token(tkn)
arc_token()
#> <httr2_token>
#> token_type: bearer
#> access_token: <REDACTED>
#> expires_at: 2024-05-02 14:22:45
#> arcgis_host: https://www.arcgis.com
Alternatively, tokens can be set based on a key-value pair.
set_arc_token("A" = tkn, "B" = tkn)
#> ✔ Named tokens set: `A` and `B`
#> ℹ Access named tokens with `arc_token("name")`
And fetched based on their name via
arc_token("A")
#> <httr2_token>
#> token_type: bearer
#> access_token: <REDACTED>
#> expires_at: 2024-05-02 14:22:45
#> arcgis_host: https://www.arcgis.com
The function arc_base_req()
is used to create a standardized httr2
request object. It handles authorization tokens and sets a user agent.
host <- arc_host() # use arcgis.com by default
arc_base_req(host)
#> <httr2_request>
#> GET https://www.arcgis.com
#> Body: empty
#> Options:
#> • useragent: 'arcgisutils v0.2.0.9002'
There are also a number of utility functions for creating and parsing Esri JSON. For example we can create a list that represent an Esri FeatureSet
using as_featurset()
directly from an sf
object. To convert to json, it is recommended to use jsonify::to_json(x, unbox = TRUE)
.
library(sf)
#> Linking to GEOS 3.11.0, GDAL 3.5.3, PROJ 9.1.0; sf_use_s2() is TRUE
nc <- st_read(system.file("shape/nc.shp", package = "sf"), quiet = TRUE)
nc_json <- as_featureset(nc)
str(nc_json, 1)
#> List of 3
#> $ geometryType : chr "esriGeometryPolygon"
#> $ spatialReference:List of 1
#> $ features :List of 100
Alternatively, you can use the set of functions with the _esri_
infix to directly create the json. See the Esri geometry reference page for more on how the conversion functions work.
Additionally, sf’s crs
object can be converted to a spatialReference
JSON object using validate_crs()
.
