Capture-recapture type experiments are used to estimate the total population size in situations when observing only a part of such population is feasible. In recent years these types of experiments have seen more interest.
Single source models are distinct from other capture-recapture models because we cannot estimate the population size based on how many units were observed in two or three sources which is the standard approach.
Instead in single source models we utilize count data regression models on positive distributions (i.e. on counts greater than 0) where the dependent variable is the number of times a particular unit was observed in source data.
This package aims to implement already existing and introduce new methods of estimating population size from single source to simplify the research process.
Currently we’ve implemented most of the frequentist approaches used in literature such as:
You can install the current version of singleRcapture from main branch GitHub with:
# install.packages("devtools")
remotes::install_github("ncn-foreigners/singleRcapture")or install the stable version from CRAN with:
install.packages(singleRcapture)The main function of this package is estimatePopsize
which fitts regression on specified distribution and then uses fitted
regression to estimate the population size.
Lets look at a model from 2003 publication : Point and interval
estimation of the population size using the truncated Poisson regression
model Heijden, Peter GM van der et al. The call to
estimatePopsize will look very similar to anyone who used
the stats::glm function:
library(singleRcapture)
model <- estimatePopsize(
formula = capture ~ gender + age + nation, # specify formula
data = netherlandsimmigrant,
popVar = "analytic", # specify
model = "ztpoisson", # distribution used
method = "IRLS", # fitting method one of three currently supported
controlMethod = controlMethod(silent = TRUE) # ignore convergence at half step warning
)
summary(model) # a summary method for singleR class with standard glm-like output and population size estimation resutls
#>
#> Call:
#> estimatePopsize.default(formula = capture ~ gender + age + nation,
#> data = netherlandsimmigrant, model = "ztpoisson", method = "IRLS",
#> popVar = "analytic", controlMethod = controlMethod(silent = TRUE))
#>
#> Pearson Residuals:
#> Min. 1st Qu. Median Mean 3rd Qu. Max.
#> -0.486442 -0.486442 -0.298080 0.002093 -0.209444 13.910844
#>
#> Coefficients:
#> -----------------------
#> For linear predictors associated with: lambda
#> Estimate Std. Error z value P(>|z|)
#> (Intercept) -1.3411 0.2149 -6.241 4.35e-10 ***
#> gendermale 0.3972 0.1630 2.436 0.014832 *
#> age>40yrs -0.9746 0.4082 -2.387 0.016972 *
#> nationAsia -1.0926 0.3016 -3.622 0.000292 ***
#> nationNorth Africa 0.1900 0.1940 0.979 0.327398
#> nationRest of Africa -0.9106 0.3008 -3.027 0.002468 **
#> nationSurinam -2.3364 1.0136 -2.305 0.021159 *
#> nationTurkey -1.6754 0.6028 -2.779 0.005445 **
#> ---
#> Signif. codes: 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
#>
#> AIC: 1712.901
#> BIC: 1757.213
#> Residual deviance: 1128.553
#>
#> Log-likelihood: -848.4504 on 1872 Degrees of freedom
#> Number of iterations: 8
#> -----------------------
#> Population size estimation results:
#> Point estimate 12690.35
#> Observed proportion: 14.8% (N obs = 1880)
#> Std. Error 2808.169
#> 95% CI for the population size:
#> lowerBound upperBound
#> normal 7186.444 18194.26
#> logNormal 8431.275 19718.32
#> 95% CI for the share of observed population:
#> lowerBound upperBound
#> normal 10.332927 26.16037
#> logNormal 9.534281 22.29793We implemented a method for plot function to visualise
the model fit and other useful diagnostic information. One of which is
rootogram, a type of plot that compares fitted and observed
marginal frequencies:
plot(model, plotType = "rootogram")
The possible values for plotType argument are:
qq - the normal quantile-quantile plot for pearson
residuals.marginal - a matplot comparing fitted and
observed marginal frequencies.fitresid - plot of linear predictor values contrasted
with pearson residuals.bootHist - histogram of bootstrap sample.rootogram - rootogram, example presented above.dfpopContr - contrasting two deletion effects to
identify presence of influential observations.dfpopBox - boxplot of results from dfpopsize function
see its documentation.scaleLoc - scale-location plot.cooks - plot of cooks.values for
distributions for which it is defined.hatplot - plot of hatvalues.strata - plot of confidence intervals for selected such
populations.a user can also pass arguments to specify additional information such
as plot title, subtitle etc. similar to calling plot on
some data. For more info check plot.singleR method
documentation.
As we have seen there are some significant differences between fitted and observed marginal frequencies. To check our intuition let’s perform goodness of fit test between fitted and observed marginal frequencies.
To do it we call a summary function of
marginalFreq function which computes marginal frequencies
for the fitted singleR class object:
summary(marginalFreq(model), df = 2, dropl5 = "group")
#> Test for Goodness of fit of a regression model:
#>
#> Test statistics df P(>X^2)
#> Chi-squared test 50.06 2 1.3e-11
#> G-test 34.31 2 3.6e-08
#>
#> --------------------------------------------------------------
#> Cells with fitted frequencies of < 5 have been grouped
#> Names of cells used in calculating test(s) statistic: 1 2 3Finally let us check if we have any influential observations. We will do this by comparing the deletion effect of every observation on population size estimate by removing it entirely from the model (from population size estimate and regression) and by only omitting it in pop size estimation (this is what is called the contribution of an observation). If observation is not influential these two actions should have the approximately the same effect:
plot(model, plotType = "dfpopContr")
it is easy to deduce from the plot above that we have influential observations in our dataset (one in particular).
Lastly singleRcapture offers some posthoc procedures for
example a function stratifyPopsize that estimates sizes of
user specified sub populations and returns them in a
data.frame:
stratifyPopsize(model, alpha = c(.01, .02, .03, .05), # different significance level for each sub population
strata = list(
"Females from Surinam" = netherlandsimmigrant$gender == "female" & netherlandsimmigrant$nation == "Surinam",
"Males from Turkey" = netherlandsimmigrant$gender == "male" & netherlandsimmigrant$nation == "Turkey",
"Younger males" = netherlandsimmigrant$gender == "male" & netherlandsimmigrant$age == "<40yrs",
"Older males" = netherlandsimmigrant$gender == "male" & netherlandsimmigrant$age == ">40yrs"
))
#> name Observed Estimated ObservedPercentage StdError
#> 1 Females from Surinam 20 931.469 2.147146 955.0676
#> 2 Males from Turkey 78 1291.251 6.040652 741.0066
#> 3 Younger males 1391 7337.072 18.958516 1282.1419
#> 4 Older males 91 1542.189 5.900703 781.4754
#> normalLowerBound normalUpperBound logNormalLowerBound logNormalUpperBound
#> 1 -1528.62209 3391.560 119.2661 8389.178
#> 2 -432.58790 3015.090 405.4127 4573.791
#> 3 4554.70841 10119.436 5134.8113 10834.792
#> 4 10.52561 3073.853 630.7551 3992.677
#> confLevel
#> 1 0.01
#> 2 0.02
#> 3 0.03
#> 4 0.05strata argument may be specified in various ways for
example:
stratifyPopsize(model, strata = ~ gender / age)
#> name Observed Estimated ObservedPercentage StdError
#> 1 gender==female 398 3811.0924 10.443200 1153.9749
#> 2 gender==male 1482 8879.2613 16.690578 1812.0813
#> 3 genderfemale:age<40yrs 378 3169.8272 11.924940 880.9491
#> 4 gendermale:age<40yrs 1391 7337.0721 18.958516 1282.1419
#> 5 genderfemale:age>40yrs 20 641.2651 3.118835 407.5268
#> 6 gendermale:age>40yrs 91 1542.1892 5.900703 781.4754
#> normalLowerBound normalUpperBound logNormalLowerBound logNormalUpperBound
#> 1 1549.34322 6072.842 2189.0439 6902.140
#> 2 5327.64720 12430.875 6090.7752 13354.889
#> 3 1443.19883 4896.456 1904.3121 5484.622
#> 4 4824.12025 9850.024 5306.3298 10421.088
#> 5 -157.47265 1440.003 212.3382 2026.728
#> 6 10.52561 3073.853 630.7551 3992.677
#> confLevel
#> 1 0.05
#> 2 0.05
#> 3 0.05
#> 4 0.05
#> 5 0.05
#> 6 0.05The package was designed with convenience in mind, for example it is possible to specify that weights provided on call are to be interpreted as number of occurrences of units in each row:
df <- netherlandsimmigrant[, c(1:3,5)]
df$ww <- 0
### this is dplyr::count without dependencies
df <- aggregate(ww ~ ., df, FUN = length)
summary(estimatePopsize(
formula = capture ~ nation + age + gender,
data = df,
model = ztpoisson,
weights = df$ww,
controlModel = controlModel(weightsAsCounts = TRUE)
))
#>
#> Call:
#> estimatePopsize.default(formula = capture ~ nation + age + gender,
#> data = df, model = ztpoisson, weights = df$ww, controlModel = controlModel(weightsAsCounts = TRUE))
#>
#> Pearson Residuals:
#> Min. 1st Qu. Median Mean 3rd Qu. Max.
#> -317.6467 -2.4060 3.7702 0.0803 13.4920 183.2108
#>
#> Coefficients:
#> -----------------------
#> For linear predictors associated with: lambda
#> Estimate Std. Error z value P(>|z|)
#> (Intercept) -1.3411 0.2149 -6.241 4.35e-10 ***
#> nationAsia -1.0926 0.3016 -3.622 0.000292 ***
#> nationNorth Africa 0.1900 0.1940 0.979 0.327398
#> nationRest of Africa -0.9106 0.3008 -3.027 0.002468 **
#> nationSurinam -2.3364 1.0136 -2.305 0.021159 *
#> nationTurkey -1.6754 0.6028 -2.779 0.005445 **
#> age>40yrs -0.9746 0.4082 -2.387 0.016972 *
#> gendermale 0.3972 0.1630 2.436 0.014832 *
#> ---
#> Signif. codes: 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
#>
#> AIC: 1712.901
#> BIC: 1757.213
#> Residual deviance: 1128.553
#>
#> Log-likelihood: -848.4504 on 1872 Degrees of freedom
#> Number of iterations: 8
#> -----------------------
#> Population size estimation results:
#> Point estimate 12690.35
#> Observed proportion: 14.8% (N obs = 1880)
#> Std. Error 2808.169
#> 95% CI for the population size:
#> lowerBound upperBound
#> normal 7186.444 18194.26
#> logNormal 8431.275 19718.32
#> 95% CI for the share of observed population:
#> lowerBound upperBound
#> normal 10.332927 26.16037
#> logNormal 9.534281 22.29793Methods such as regression diagnostics will be adjusted (values of weights will be reduced instead of rows being removed etc.)
We also included option to use common non standardargument such as significance levels different from usual 5%:
set.seed(123)
modelInflated <- estimatePopsize(
formula = capture ~ gender + age,
data = netherlandsimmigrant,
model = "oiztgeom",
method = "IRLS",
# control parameters for population size estimation check documentation of controlPopVar
controlPopVar = controlPopVar(
alpha = .01, # significance level
)
)
summary(modelInflated)
#>
#> Call:
#> estimatePopsize.default(formula = capture ~ gender + age, data = netherlandsimmigrant,
#> model = "oiztgeom", method = "IRLS", controlPopVar = controlPopVar(alpha = 0.01,
#> ))
#>
#> Pearson Residuals:
#> Min. 1st Qu. Median Mean 3rd Qu. Max.
#> -0.357193 -0.357193 -0.357193 0.000343 -0.287637 10.233608
#>
#> Coefficients:
#> -----------------------
#> For linear predictors associated with: lambda
#> Estimate Std. Error z value P(>|z|)
#> (Intercept) -1.5346 0.1846 -8.312 < 2e-16 ***
#> gendermale 0.3863 0.1380 2.800 0.00512 **
#> age>40yrs -0.7788 0.2942 -2.648 0.00810 **
#> -----------------------
#> For linear predictors associated with: omega
#> Estimate Std. Error z value P(>|z|)
#> (Intercept) -1.7591 0.3765 -4.673 2.97e-06 ***
#> ---
#> Signif. codes: 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
#>
#> AIC: 1736.854
#> BIC: 1759.01
#> Residual deviance: 1011.271
#>
#> Log-likelihood: -864.4272 on 3756 Degrees of freedom
#> Number of iterations: 6
#> -----------------------
#> Population size estimation results:
#> Point estimate 5661.522
#> Observed proportion: 33.2% (N obs = 1880)
#> Std. Error 963.9024
#> 99% CI for the population size:
#> lowerBound upperBound
#> normal 3178.674 8144.370
#> logNormal 3861.508 9096.681
#> 99% CI for the share of observed population:
#> lowerBound upperBound
#> normal 23.08343 59.14416
#> logNormal 20.66688 48.68564and the option to estimate standard error of population size estimate by bootstrap, models with more than one distribution parameter being dependent on covariates and some non standard link functions for example:
modelInflated2 <- estimatePopsize(
formula = capture ~ age,
data = netherlandsimmigrant,
popVar = "bootstrap",
model = oiztgeom(omegaLink = "cloglog"),
method = "IRLS",
controlPopVar = controlPopVar(
B = 500,# number of boostrap samples
alpha = .01, # significance level
# type of bootstrap see documentation for estimatePopsize
bootType = "semiparametric",
# control regression fitting on bootstrap samples
bootstrapFitcontrol = controlMethod(
epsilon = .Machine$double.eps,
silent = TRUE,
stepsize = 2
)
),
controlModel = controlModel(omegaFormula = ~ gender) # put covariates on omega i.e. the inflation parameter
)
#> Warning in singleRcaptureinternalIRLSmultipar(dependent = y, covariates = X, :
#> Convergence at halfstepsize
#> Warning in estimatePopsize.default(formula = capture ~ age, data = netherlandsimmigrant, : The (analytically computed) hessian of the score function is not negative define.
#> NOTE: Second derivative test failing does not
#> necessarily mean that the maximum of score function that was found
#> numericaly is invalid since R^k is not a bounded space.
#> Additionally in one inflated and hurdle models second derivative test often fails even on valid arguments.
#> Warning in estimatePopsize.default(formula = capture ~ age, data =
#> netherlandsimmigrant, : Switching from observed information matrix to Fisher
#> information matrix because hessian of log-likelihood is not negative define.
popSizeEst(modelInflated2)
#> Point estimate: 5496.374
#> Variance: 1217985
#> 99% confidence intervals:
#> lowerBound upperBound
#> 4002.763 10231.717the results are significantly different (the warning issued concerns the second derivative test for existence of local minimum, here it was inconclusive but we manually checked that fitting process found the optimal regression coefficients it’s here to provide more information to the user):
plot(modelInflated2,
plotType = "bootHist",
labels = TRUE,
ylim = c(0, 175),
breaks = 15)
and information criteria support the second model:
#> First model: AIC = 1736.854 BIC = 1759.01
#> Second model: AIC = 1734.803 BIC = 1756.959Work on this package is supported by the the National Science Center, OPUS 20 grant no. 2020/39/B/HS4/00941.
These binaries (installable software) and packages are in development.
They may not be fully stable and should be used with caution. We make no claims about them.
